€2,356.00
The Mavimare GE 350 is a heavy-duty hydraulic steering system designed for demanding workboat applications. It delivers reliable control with a 14-plunger pump producing up to 80 bar pressure and 70 cm³ displacement. The system includes a steering cylinder with 550 cm³ volume, 55 mm bore, and 300 mm stroke, providing a maximum torque of 340 kgm at 35 degrees. Complete with two 7.5-meter hoses that
Category : outboards motors for sale
SKU : 7f99166a
Tags : boat steering kit, heavy duty marine steering, hydraulic pump 80 bar, hydraulic steering system, marine steering cylinder, Mavimare GE 350, workboat steering
Brand: MavimareThe Mavimare GE 350 is a heavy-duty hydraulic steering system designed for demanding workboat applications. It delivers reliable control with a 14-plunger pump producing up to 80 bar pressure and 70 cm³ displacement. The system includes a steering cylinder with 550 cm³ volume, 55 mm bore, and 300 mm stroke, providing a maximum torque of 340 kgm at 35 degrees. Complete with two 7.5-meter hoses that can be custom-cut using heavy-duty clamp couplings, three bottles of hydraulic oil, a vent hose, and all necessary mounting hardware. The pump can also be recess-mounted. Assembly is straightforward with the included English installation manual. This robust system is built for longevity and ease of maintenance in commercial marine environments.
| Brand | Mavimare |
| Model | GE 350 |
| Type | Hydraulic Steering System |
| Pump Weight | 7.5 kg |
| Max Pump Pressure | 80 bar |
| Number of Plungers | 14 |
| Pump Displacement | 70 cm³ |
| Cylinder Displacement | 550 cm³ |
| Cylinder Bore Diameter | 55 mm |
| Cylinder Stroke | 300 mm |
| Cylinder Weight | 16 kg |
| Max Cylinder Pressure | 86 bar |
| Max Torque | 340 kgm at 35° |
| Number of Turns | 8 |
| Hose Length (each) | 7.5 m |
| Components Included | Hydraulic pump, steering cylinder, 2 hydraulic hoses, 3 bottles of hydraulic oil, vent hose, mounting hardware, English manual |
| Weight | 66.14 lbs |
|---|---|
| Dimensions | 31.5 × 19.69 × 15.75 in |
| Brand | Mavimare |
